100 SERlES Inward Opening System

Description

The 100 SERIES Inward Opening System from ZCSUNG System Doors and Windows represents the pinnacle of modern design and engineering, seamlessly blending aesthetic appeal with practical functionality to redefine living spaces. Every detail is crafted to deliver an exceptional user experience, from its sleek appearance to its advanced performance features.

A standout aspect of this system is its versatile glass configuration, offering two high-performance options: 5+20Ar+5 and 5+12Ar+5+12Ar+5 insulated tempered glass. Both configurations are filled with argon gas and undergo homogenization treatment, ensuring superior thermal insulation, soundproofing, and safety. The argon gas filling enhances the glass's ability to resist heat transfer, maintaining a stable indoor temperature year-round, while the homogenization treatment minimizes the risk of spontaneous breakage, adding a layer of reliability. The glass utilizes Xinyi original sheets (VP grade), guaranteeing exceptional clarity for unobstructed views, and is framed with black one-piece bent aluminum strips that not only elevate the visual appeal but also reinforce the glass unit's structural integrity.

The ultra-narrow mullion design is another defining feature, characterized by clean, 简约线条 (simple lines) that maximize the glass area and create a sense of openness. This design choice not only enhances the system's modern aesthetic but also allows more natural light to flood into the space, making interiors feel brighter and more spacious.

In terms of sealing performance, the 100 SERIES sets a high standard with three seals, including EPDM rubber strips and integrally welded isobaric rubber strips. These components work in harmony to form an airtight barrier, effectively blocking dust, rain, and wind from entering the indoor environment. The EPDM rubber strips are renowned for their durability and resistance to aging, ensuring long-term sealing effectiveness, while the integrally welded isobaric rubber strips maintain consistent pressure, further enhancing the system's ability to keep interiors clean and comfortable.

The flush frame and sash both inside and outside contribute to the system's sleek, seamless look, adding a touch of sophistication to any architectural style. Complementing this, the glass sash features an R7 rounded corner design, which not only enhances visual appeal but also significantly improves safety. The smooth, rounded edges reduce the risk of accidental bumps and injuries, making it an ideal choice for families with children and pets—proving that beauty and safety can coexist harmoniously.

Energy efficiency is prioritized with the inclusion of PA66GF25 thermal insulation strips and a vertical isotherm design. The thermal insulation strips minimize heat transfer, reducing reliance on heating and cooling systems and lowering energy consumption. The vertical isotherm design ensures uniform temperature distribution across the system, contributing to a more energy-efficient and eco-friendly living space.

Operational versatility is a key strength of the 100 SERIES, featuring a glass sash that opens inward and tilts. This design allows for multiple ventilation options: fully opening the sash for maximum airflow or tilting it slightly for gentle, controlled ventilation without compromising security. For added convenience, it can be optionally equipped with magnetic control shutters or electric shutters, enabling easy adjustment of light intake and privacy as needed.

The screen sash opens inward and can be disassembled without tools for easy cleaning and maintenance, adding to the system's user-friendly design. A range of screen options is available, including diamond mesh, high-definition mesh, and high-transparency mesh, allowing users to choose based on their specific needs. These screens effectively prevent mosquitoes, keep dust at bay, and are highly durable, ensuring long-lasting performance even with frequent use.

In conclusion, the ZCSUNG 100 SERIES Inward Opening System is a perfect synergy of style, functionality, safety, and energy efficiency. Its ultra-narrow mullion design, superior glass configurations, advanced sealing, and user-friendly features make it an ideal choice for those seeking to enhance their living spaces with a system that combines aesthetic elegance with practical performance. It stands as a testament to ZCSUNG's commitment to innovation and excellence in door and window systems.

Specifications
