ZCSUNG 80 SERIES Aluminum Outward Opening Window | Durable Aluminum Casement Window From Professional Source Factory
- Overview
- Recommended Products
| Place of Origin: | China |
| Brand Name: | ZCSUNG DOOR&WINDOW SYSTEM |
| Model Number: | 80 SERlES |
Description
The 80 SERIES Outward Opening System launched by ZCSUNG System Doors and Windows integrates stylish appearance, practical functions and long service life. As a professional source factory engaged in customized window manufacturing, we tailor this premium aluminum casement window, namely the aluminum outward opening window, to satisfy all kinds of modern architectural requirements with reliable performance and minimalist fashionable design. Every meticulous detail is polished to bring premium usage experience, rendering it a popular pick for residential houses, villas and commercial buildings alike.
Its core adopts standard 5+20Ar+5 insulated tempered glass filled with argon gas and processed through homogenization treatment. Such glass structure brings outstanding thermal insulation and sound insulation effects, keeping indoor temperature comfortable all year long and isolating outdoor noise efficiently. Argon filling improves thermal performance, and homogenization treatment greatly lowers the probability of glass self-explosion for higher safety stability. This aluminum outward opening windowadopts VP-grade original Xinyi glass panels to realize ultra-high transparency and panoramic sightseeing experience, matched with integrated bent black aluminum strips. These strips strengthen structural firmness as well as endow the window with modern elegant texture.
This aluminum casement window adopts medium narrow frame design matched with closed square molding lines to create a simple and elegant texture. The structure expands glass coverage to admit more natural light, meanwhile delivers neat geometric texture that matches most indoor and outdoor architectural styles. Both frame and sash adopt internal & external flush design for smooth integrated visual effect, and the window sash is designed with R7 rounded corners. The rounded corners upgrade the overall aesthetics and prevent users from accidental collision injuries, making this aluminum outward opening window very suitable for families with kids.
Excellent sealing property is the core advantage of the 80 SERIES aluminum window. It is constructed with triple sealing structure consisting of EPDm rubber strips and integrally welded isobaric sealing strips. The multi-layer sealing structure can effectively block dust, rainwater and strong wind from entering the room, so as to maintain a clean and comfortable living environment. Aging-resistant EPDM sealing strips keep stable sealing performance for years, and integrally welded isobaric rubber strips maintain balanced pressure continuously to further promote airtight performance of this aluminum casement windowsupplied directly by our source factory.
Energy-saving performance is upgraded via PA66GF25 thermal insulation strips plus vertical isotherm design. Heat insulation strips block indoor and outdoor heat conduction, decrease the usage frequency of air conditioners and heating equipment, thus cutting energy expenditure. Vertical isotherm layout guarantees even temperature distribution, helping build energy-saving and eco-friendly living spaces with our factory-made aluminum outward opening window.
For opening modes, the 80 SERIES aluminum outward opening window supports standard outward opening style, and can be upgraded to outward opening + top-hung ventilation combination mode according to demands. Flexible ventilation modes meet diverse usage scenarios: fully open the window for maximum air circulation, or use top-hung mode for soft safe ventilation when nobody is at home. Magnetic control shutters and electric shutters are optional accessories to freely adjust indoor brightness and privacy level for extra convenience.
In conclusion, ZCSUNG 80 SERIES Outward Opening System perfectly combines aesthetic sense, safety and practical performance. With premium glass collocation, minimalist frame design, strong sealing capacity and flexible opening methods, this high-performance aluminum casement window is ideal for property owners who want to upgrade living space with stylish, practical and energy-saving windows. As a trustworthy source factory specializing in aluminum window production, ZCSUNG adheres to innovation and superb craftsmanship in system door and window manufacturing, providing global clients with cost-effective customized aluminum outward opening window solutions without middlemen markup.
| Wind pressure resistance | 9级P3=5.0KPa GB/T7106-2019 |
| water-tightness, water proofness, water tightness | 6级△P≥500Pa GB/T 7106-2019 |
| gas tightness, airtightness | 8级q1≤1.0m/m·h GB/T7106-2019 |
| Sound insulation | 38db GB/T 8485-2008 |
| Insulation | 1.4-1.8W/m²·K GB/T8484-2020 |
| Corrosion resistance>240 hours of salt spray test | |
Specifications
| Frame Thickness/Profile Wall Thickness: | 80/1.8-2.0 (mm), 6063-T5 high precision grade |
| Connection process: | One-piece angle code group corner glue process |
| Hardware standard | CMECH outward opening hardware system screen window |
| Window screen optional | Hide the folding screen |
| Baffle limit dimensions： | Wide≤750mm，high≤160000mm |
