Customized Soundproof Thermal Break Aluminum Windows Home Use Double Glazed Tempered Glass Living Room Casement Window
- Overview
- Recommended Products
| Place of Origin: | China |
| Brand Name: | ZCSUNG DOOR&WINDOW SYSTEM |
| Model Number: | Open inside SERlES |
Product Description
ZCSUNG’s 101MAX inward tilt & turn aluminum window redefines high-end residential and commercial glazing solutions by merging state-of-the-art manufacturing tech, delicate workmanship and multi-scenario practical functions, bringing top-tier performance, elegant styling and effortless operation to modern buildings.
.
This window comes factory-fitted with premium 5+20Ar+5 hollow tempered insulated glass filled with inert argon gas and processed through homogenization treatment. This composite glazing greatly boosts thermal retention and noise reduction while eliminating the hidden danger of spontaneous glass cracking for long-term safety. It adopts VP-grade Xinyi ultra-clear raw glass panels that deliver exceptional light transmission and unobstructed outdoor scenery. An innovative nano formaldehyde purification coating is applied on the glass surface to decompose harmful formaldehyde indoors and build a healthier living atmosphere. Integrated curved black aluminum spacers are matched to reinforce the glass assembly structure and deliver a refined minimalist look.
.
Its decorative large chamfered molding for fixed glass brings distinctive geometric layering and premium texture, making the 101MAX series a standout decorative element that balances visual beauty and practical utility for all architectural styles.
.
The inner and outer surfaces of the frame and sash adopt a full flush flat design for a streamlined integrated look that coordinates with all interior and exterior decoration schemes. The window sash is manufactured via seamless welding craft for a smooth gap-free surface, paired with soft R7 rounded corners to prevent accidental bumps, perfectly fitting households with kids and pets. Custom arched curved profiles are available for personalized styling, and the window can also be installed as a safety glass balustrade to expand its applicable scenarios.
.
Triple sealing construction establishes outstanding weather resistance for this tilt & turn window, composed of wear-resistant EPDM rubber gaskets and integrally welded equal-pressure sealing strips. The coordinated sealing structure fully blocks wind, rain and dust from penetrating indoors. EPDM material resists aging for decades to maintain stable sealing capacity, while the integrated equal-pressure rubber strips balance internal and external air pressure to further upgrade waterproof and windproof effects.
.
Equipped with 41mm extra-wide thermal break strips paired with vertical equal-temperature structural design, this window effectively blocks heat exchange between indoor and outdoor sides. It cuts air conditioner and heater power consumption all year round with balanced temperature distribution across the whole window frame, achieving superior energy-saving and eco-friendly performance.
.
The dual-function inward tilt and swing sash offers flexible ventilation modes: fully inward swing for maximum air circulation, or micro tilting for gentle fresh air intake while keeping the house secured. Magnetic or motorized roller shutters are optional attachments to freely adjust indoor light brightness and privacy levels based on user demands.
.
The inward-opening screen sash supports tool-free quick disassembly to facilitate daily washing and maintenance. Three replaceable mesh choices are provided: diamond security mesh, high-definition invisible mesh and high light-transmittance mesh. All screen variants reliably block mosquitoes and floating dust, with sturdy woven fabric to sustain stable performance under long-term repeated use.
.
To sum up, ZCSUNG 101MAX inward tilt & turn aluminum window perfectly combines luxury aesthetics, all-around practical performance and innovative functional design. Featuring formaldehyde-purifying insulated glass, seamless flush frame appearance, diverse custom solutions and humanized daily-use details, this thermal break casement window integrates health protection, household safety and timeless minimalist design. It fully demonstrates ZCSUNG’s persistent pursuit of technological breakthroughs and premium quality in aluminum door and window system manufacturing.
| Wind pressure resistance | 9级P3=5.0KPa GB/T7106-2019 |
| water-tightness, water proofness, water tightness | 6级△P≥500Pa GB/T 7106-2019 |
| gas tightness, airtightness | 8级q1≤1.0m/m·h GB/T7106-2019 |
| Sound insulation | 35-40db GB/T 8485-2008 |
| Insulation | 1.3-1.8W/m²·K GB/T8484-2020 |
| Corrosion resistance>240 hours of salt spray test | |
Specifications
| Frame Thickness/Profile Wall Thickness: | 1.8 (mm), 6063-T5 high precision grade |
| Connection process: | One-piece angle code group corner glue process |
| Hardware standard | CMECH internal open and inverted hardware system |
| Fan thickness | 72.8MM |
| Baffle limit dimensions： | wide ≤850mm，high≤2700mm |
